IBS COUPLER

A directional coupler is a 4-port device that is used to sample a small amount of input signal power for measurement purposes. As seen in the diagram below, Port 1 is the input port, port 2 is the output port, port 3 is the coupled port and port 4 is the isolated/terminated port.
